96 iDirect Satellite Router Installation and Commissioning Guide
iDX Release 3.3
Front-Panel LEDs
16.3.3 Evolution X1
Ta b l e 9 contains LED definitions for the Evolution X1 Satellite Routers.
Note: Evolution X1 Outdoor Satellite Routers have only one LED
(POWER) on the front
panel. However, the LEDs in Tabl e 9 are simulated by the Web iSite user
interface. Log in to Web iSite to view the status indicators.
Table 9. iDirect Evolution X1 LED Definitions
Label Color Definition
RX Off Receiver off or not configured
Yellow Demodulator not locked to the downstream
carrier
Flashing Yellow Demodulator locked. NCR not locked.
Green Demodulator locked. NCR locked.
Flashing Green (1 sec) DRAM test failed (TX and NET a
lso flashing green)
Flashing Red All LEDs flashing red: software except
ion or bad options file
TX Off Transmitter off.
Yellow Transmitter enabled and muted
Green Transmitter enabled and not muted
Flashing Green (1 sec) DRAM test failed (RX and
NET als
o flashing green)
Flashing Red All LEDs flashing red: software except
ion or bad options file
NET Off Satellite Router off or in sleep mode if TX is yellow
Ye
llow Demodulator not locked to the downstream
carrier
Flashing Yellow Demodulator locked. NCR not locked.
Fla
shing Green (2 sec) Demodulator locked. NCR lock
ed.
Flashing Green (1 sec) Network acquisition in progress
Flashing Green (1 sec) DRAM test failed (RX and TX a
lso flashing green)
Green The Satellite Router is in the network
Flashing Red All LEDs flashing red: software exce
pt
ion or bad options file
POWER Off No power or low power input
Green Valid power input detected
Flashing Red All LEDs flashing red: software except
ion or bad options file
