iDirect Satellite Router Installation and Commissioning Guide 65

iDX Release 3.3

Peaking the Antenna

If both the software package and options file have already been loaded on the Satellite

Router, and the remote site is not being configured as a secure mobile, proceed to

“Cross

Polarization” on page79.

If both the software package and options file

have

already been loaded on the Satellite

Router, and the remote site is being configured as a secure mobile, proceed to “Setting Geo

Location for Secure Mobiles” on page75.

If using the Downstream Template feature to download both software and configuration (X7

only) or configuration only

over-the-air, proceed to “Over the Air Download” on page67.
