IDS 816 Installer Manual

IDS 816 700-283-02I Issued September 2009
35
NOTE:
 The panel may be programmed to report to a single central station (single reporting) or to report
to 2 central stations (dual reporting).
 When programmed for single reporting, the panel default will alternate attempts between the two
“equally ranked” stored numbers. With LED 4 on, the secondary number will only be called if the
attempt to report to the primary number fails. In either case, the number of attempts (per phone
number) will be equal to the number stored in location 115, with a default value of 6.
 The primary and secondary telephone numbers may be joined to provide for a single telephone
number of 48 digits in length.
LOCATION 112 Auto Test Interval
Value
Time Period
0 Report every hour
1
Report daily (default)
2 Every two days
3 Every three days
4 Every four days
5 Every five days
6 Every six days
7 Every seven days
8 Every eight days
9 Every nine days
10 Every ten days
11 Every eleven days
12
Every twelve days
13
Every thirteen days
14 Every fourteen days
15 Every fifteen days
The value programmed into this location will determine the duration of time between Auto Tests.
LOCATION 113 Auto Test Time
Enter the time when the auto test will be reported. The format is “hhmm” based on a 24-hour clock. (All
four digits must be entered.)
Example:
If a value of [7] was programmed into location 112 and [1400] was programmed into this location, the
auto test would be sent weekly at 2:00pm.
LOCATION 114 Number of Account Code Digits (Default = 4)
Most reporting formats use a 4-digit account code. Program a 6 into this location to enable 6-digit
account code reporting. This option is not supported by Contact ID.
LOCATION 115 Number of Dial Attempts (Default = 6)
This location determines the maximum number of dial attempts that the panel will make in order to
contact the base station.
