IDS 816 Installer Manual

IDS 816 700-283-02I Issued September 2009
47
Summary of Partition Event Driven Programmable Outputs
Sub-loc
Event
Output
Default Action
21 Close programmable output 3 Set high [0]
22 Stay close programmable output Disabled
23 Open programmable output 3 Set low [1]
24 Cancel programmable output Disabled
25 Alarm restoral programmable output Disabled
26 Bypass programmable output Disabled
27 Forced arm programmable output Disabled
28 Zone tamper programmable output Disabled
29
Zone tamper restoral programmable
output
Disabled
30 Zone shutdown programmable output Disabled
31
Zone shutdown restoral
programmable output
Disabled
32 Keypad panic programmable output 1 Pulse high [2]
33 Keypad fire programmable output Disabled
34
Keypad medical programmable
output
Disabled
35 Keypad lockout programmable output Disabled
36 Duress programmable output 1 Pulse high [2]
37 Verifies alarm programmable output Disabled
38 Burglary programmable output 2 Pulse high [2]
39 Panic programmable output 1 Pulse high [2]
40 Fire programmable output Disabled
41 Tamper zone programmable output Disabled
42 Siren programmable output Disabled
43
Strobe programmable output
Disabled
44
Chime programmable output
Disabled
Sub-location 45 Clear Programmable Outputs on Disarming
This bitmapped sub-location allows any programmable output to be cleared (set low) on disarming.
The output(s) to be cleared will be displayed by zone LED’s that are on, representing the
output i.e. zone 1 = output 1 etc. To toggle the status of the output, press the [NUMBER OF OUTPUT]
[*] if the LED was off it will now come on and visa versa.
(To exit this mode press [#])
LED
Output
1 Panel - programmable output 1
2 Panel - programmable output 2
3 Panel - programmable output 3
4 Panel - programmable output 4
5
Panel - programmable output 5
6
Wired zone expander - programmable output 2
7 Wired zone expander - programmable output 1
