ifm Programming Manual ecomatmobile BasicController (CR0403) Runtime System V03.02 2015-04-01
ifm function elements ifm function elements for the device CR0403
>
Output parameters
8523
CURRENT WORD only available for current controlable outputs:
current output current in [mA]
RESULT BYTE feedback of the function block
(possible messages → following table)
Possible results for RESULT:
Value
dec | hex
Description
0 00 FB is inactive
1 01 FB execution completed without error – data is valid
2 02 function block is active (action not yet completed)
3 03 function block is active – valid values not yet available
128 80 undervoltage on VBBx
130 82 channel setting is invalid
131 83 value for VALUE is invalid
132 84 mode setting is invalid
133 85 value for FREQUENCY is invalid
134 86 dither setting is invalid
