ifm Programming Manual ecomatmobile BasicController (CR0403) Runtime System V03.02 2015-04-01
ifm function elements ifm function elements for the device CR0403
>
Parameters of the outputs
7617
MATCHED_ID DWORD number of the data object identifier
DATALENGTHCOUNT BYTE = Data Length Count
number of the data bytes received
DATA ARRAY [0..7] OF BYTE received data, (1...8 bytes)
MORE_DATA_AVAILABLE BOOL TRUE: further received data available in the FiFo
FALSE: no further data available in the FiFo
RESULT BYTE feedback of the function block
(possible messages → following table)
Possible results for RESULT:
Value
dec | hex
Description
0 00 FB is inactive
1 01 function block execution completed without error
5 05 FB is being processed – still receiving
9 09 CAN is not active
242 F2 Error: setting is not possible
250 FA Error: FiFo is full – data was lost
