ifm Programming Manual ecomatmobile BasicController (CR0403) Runtime System V03.02 2015-04-01
ifm function elements ifm function elements for the device CR0403
>
Parameters of the outputs
7598
Parameter
Data type
Description
ID DWORD Number of the data object identifier:
normal frame (2
11
IDs):
0...2 047 = 0x0000 0000...0x0000 07FF
Extended Frame (2
29
IDs):
2 048...536 870 911 = 0x0000 0800...0x1FFF FFFF
DATALENGTHCOUNT BYTE = Data Length Count
number of the data bytes received
DATA ARRAY [0..7] OF BYTE received data, (1...8 bytes)
RESULT BYTE feedback of the function block
(possible messages → following table)
Possible results for RESULT:
Value
dec | hex
Description
0 00 FB is inactive
1 01 function block execution completed without error
5 05 FB is being processed – still receiving
9 09 CAN is not active
242 F2 Error: setting is not possible
