DP2200 Analogue threshold display

8 Menu

8.1 General

Irrespective of the operating mode (standard IO mode or IO-Link device) there are two options to set

the parameters of the unit:

• directly on the device via the menu (Ò Parameter setting)

• or via an IO-Link tool

Access via an IO-Link tool has a higher priority than parameter setting via the menu.

Parameter cloning and parameter setting backup is possible with an IO-Link tool.

Some parameters can only be set via the IO-Link interface:

Parameters adjustable via IO-Link.

If the device was locked via IO-Link, it can also only be unlocked via the IO-Link interface:

Locking / unlocking (Ò/22).

The scaling parameter [ScAL] only influences the display and not the transferred process data or the

actual switching threshold values.

Via IO-Link, the current value is always transmitted in μA → Representation of the measured current

value (Ò/13). The switching thresholds can be set in steps of 0.01 mA.

If a scaling is set, the menu settings of the switching thresholds (SP, rP etc.) are also scaled.

Via IO-Link, however, the settings continue to be displayed and executed in steps of 0.01 mA

(resolution 10 bits).
