DP2200 Analogue threshold display
26
13 Factory settings
Parameter Factory settings User settings
SP1/FH1 Set point OUT1 6.00
rP1/FL1 Reset point OUT1 5.00
A.Trm Analogue termination OUT2 On • OFF
• On
ou1 Output function OUT1 Hno • Hno
• Hnc
• Fno
• Fnc
dS1 Switching delay OUT1 0.0 s
dr1 Switch-off delay OUT1 0.0 s
ScAL Scaling value OFF • OFF
• cccc
• ccc.c
• cc.cc
• c.ccc
C.ASP Customised analogue start
point
----
C.AEP Customised analogue end
point
----
C.uni * Customer-specific unit mA
coLr Display: colour setting rEd • rEd
• grEn
• r1ou
• G1ou
• r-cF
• G-cF
cFH Colour change: upper limit
value
20.0
cFL Colour change: lower limit
value
4.0
diS Display refresh rate d2 (200 ms) • OFF
• d1 (50 ms)
• d2 (200 ms)
• d3 (600 ms)
Lo Lowest measured input value ----
Hi Highest measured input value ----
dAP Damping of the measured an-
alogue value
0.060 s
(= 60 ms)
*) can only be configured via IO-Link and parameter setting software:
Parameters adjustable via IO-Link (Ò/19)
