IFM PI2897 - Connection for 2-wire operation; Connection for 3-wire operation

12
6.1 Connection for 2-wire operation
Core colours
Original Scale Drawing (MTD)
EPS Source
Frame Size: 15 mm x 15 mm
PIN_0180
2 1
2 1
L
+
BN1
WH2
OUT
BN brown
WH white
OUT: analogue output 4...20 mA
Colours to DIN EN 60947-5-2
6.2 Connection for 3-wire operation
Core colours
43
2 1
BN
WH
BK
BU
4
1
3
2
OUT2
L
+
L
OUT1
BK black
BN brown
BU blue
WH white
OUT1: switching output or IO-Link
OUT2: switching outputs or analogue output
Colours to DIN EN 60947-5-2
Wiring example
2 x positive switching 2 x negative switching
L
L
+
3
4
2
1
BU
BK
WH
BN
2: OUT2
4: OUT1
L
L
+
3
4
2
1
BU
BK
WH
BN
2: OUT2
4: OUT1
1 x positive switching / 1 x analogue 1 x negative switching / 1 x analogue
L
L
+
3
4
2
1
BU
BK
WH
BN
2: OUT2
4: OUT1
L
L
+
3
4
2
1
BU
BK
WH
BN
2: OUT2
4: OUT1
