9.6.2 Set simulation value
Output states
If [SEL] is active:
► Press [Set] and keep it pressed until [OU] is displayed.
► Briefly press [Mode/Enter].
> [S.OU1] is displayed (in 2-wire operation [S.OU2] is displayed).
► Press [Set] to set the requested value:
- [OPEN] = output 1 not active / open.
- [CLOS] = output 1 active / closed.
► Briefly press [Mode/Enter].
> [S.OU2] is displayed.
► Press [Set] to set the requested value:
• If [OU2] = [Hnc], [Hno], [Fnc] or [Fno] (not in 2-wire operation):
- [OPEN] = output 2 not active / open.
- [CLOS] = output 2 active / closed.
• If [OU2] = [I] or [InEG]:
- 3.60...21.10 mA in steps of 0.01 mA.
► Briefly press [Mode/Enter].
Process value
If [SEL] is active:
► Press [Set] and keep it pressed until [Proc] is displayed.
► Briefly press [Mode/Enter].
> [S.Pr] is displayed.
► Press [Set] to set the requested pressure value.
► Briefly press [Mode/Enter].
9.6.3 Set time for simulation
► Select [S.TIM] and set the value between 1...60 minutes.
9.6.4 Start simulation
► Select [S.ON].
► Press [Set] and keep it pressed until the display alternately shows [SIM]
and the current operation indication.
Current operation indication:
-Current system pressure if [SEL] = [OU].
-Simulated measured value set in [S.Pr] if [SEL] = [Proc].
After the simulation time has elapsed [S.OFF] is displayed for 2 s, then
[SEL].
Abort simulation:
► Briefly press [Mode/Enter] or [Set].
> [S.OFF] is displayed for 2 s, then [SEL].
