8.4 Explanation of the menu level 2
Uni Standard unit of measurement for system pressure.
SELd
Display mode:
• Pressure in the unit set in [Uni].
• Pressure in % of the set scaling of the analogue output.
ASP Analogue start point for system pressure: measured value at which 4 mA is
provided (20 mA if [OU2] = [InEG]).
AEP Analogue end point for system pressure: measured value at which 20 mA is
provided (4 mA if [OU2] = [InEG]).
HI Maximum value memory for system pressure.
LO Minimum value memory for system pressure.
COF Zero-point calibration.
dS1* Switch-on delay for OUT1.
dr1* Switch-off delay for OUT1.
dS2* Switch-on delay for OUT2; only active if [OU2] = [Hnc], [Hno], [Fnc] or [Fno].
dr2* Switch-off delay for OUT2; only active if [OU2] = [Hnc], [Hno], [Fnc] or [Fno].
FOU1* Status of output 1 in case of an internal fault.
FOU2 Status of output 2 in case of an internal fault.
P-n* Switching logic for the outputs: pnp or npn.
dAP Damping for switching outputs and display.
dAA Damping for analogue output (OUT2), also has effect on the IO-Link process
value.
diS Update rate and orientation of the display.
CAL Calibration function (setting the curve of measured values).
CP1 Calibration point 1
CP2 Calibration point 2
SIM Change to menu level 3 (simulation).
rES Restore factory setting.
* menu items not active in 2-wire operation
