2. Installation – Linking System 9
2. Installation – Linking System
The following diagram illustrates the connection of the whole system.
Control Box
PC Board (Slave Machines)
Up to 24 slave machines can be connected
Display
CO1
CO3
CO2
VGA
Audio
Lamp
Power Supply
Power adapter
