36 8. Bookkeeping
8. Bookkeeping
Under the linking mode, you can access the bookkeeping data either from the PC board or from
the control box.
8.1 Overall System Short/Long Term Data
From 1
st
Slave Machine
To access the bookkeeping data:
1. At the machine with slave ID1, press
[RECORD]
and then enter the password.
2. Then press
[SMALL]
.The default is pressing
[Play]
for 8 times.
3. Select to view short term or long term data as required.
Press
[RECORD]
[SMALL]
SYSTEM
PASSWORD
[BIG]
SHORT TERM
[DOUBLE]
LONG TERM
[SMALL]
ADJUSTMENT
Default password:
Press [PLAY] 8 times
[PLAY]
SET PASSWORD
[TAKE]
SYSTEM RESET
[DOUBLE]
TIME
[BIG]
SYSTEM
From Control Box
1. Using the CO4 cable, connect one end to the
LAN
port on the control box and the other end
to the
LAN
port on the computer.
2. Configure your computer to use an IP address in the same subnet as the control box’s IP.
For example:
IP address:
172.16.1.1
Subnet mask:
255.255.0.0
3. Open a browser and enter http://172.16.1.2 in the URL field.
