3
2. General Specifications
2-1. Common Specifications
(1) General
1) Power supply:
AC single phase, 50/60 Hz
Within 100V area: 100V-120V ±10%
Within 200V area: 200V-240V ±10%
2) Power consumption:
Max. 240W (with full options)
3) Ambient temperature:
0ºC to +40ºC
4) Humidity:
Below 90% (No condensation)
5) Dimensions and weight:
HTM-1517R :
450(W) x 310(H) x 515(D)mm, Approx. 28kg
HTM-1917R :
450(W) x 399(H) x 515(D)mm, Approx. 38kg
6) Standard accessories:
Power cable, remote connector, operation manual
x 1 each
7) Operation: Continuous
8) X-ray: Less than 0.1mR/H
(Anywhere 50mm or remoter from
the monitor)
(2) Video Signals System
1) Frequency response:
a)
HDTV (Input YPbPr/RGB)
60Hz~25MHz: +1dB/-3dB
More than 25MHz: Descending response
b)
SDTV (Input with DE-801 mounted)
60Hz~10MHz: +1dB/-3dB
More than 10MHz: Descending response
c)
SDTV (Input with DE-811 mounted)
60Hz~5.75MHz: ±1dB
More than 5.75MHz:Descending response
2) Sag: Within 5%
3) Black level stability:
For 10% to 90% APL changes: Within 1%
4) Aperture correction amount:
Variable +6dB or more at the frequency below
a) HDTV 12.5MHz
b)
SDTV 4MHz (With DE-801/811 in use)
5) Noise
Sync noise: More than -46dB
Hum noise: More than -50dB
Others: More than -50dB
(3) Brightness and Contrast
1) CRT Dot trio pitch:
HTM-1517R : 0.27mm
HTM-1917R : 0.25mm
2) Horizontal resolution:
With YPbPr input and 120 cd/m
2
in screen center
HTM-1517R :
More than Approx. 750lines (480i, 575i, 1080i)
HTM-1917R :
More than Approx. 900lines (480i, 575i, 1080i)
3) Preset contrast
(Factory setting)
120 cd/m
2
(35ft-L)
4) Maximum luminance
SDTV (4:3) : 170 cd/m
2
(typ)
HDTV (16:9) : 240 cd/m
2
(typ)
(100% window signal input, brightness: PRESET, contrast: MAX)
(4) Deflection/Sync System
1) Display size
a) NORMAL: 1% over
b) UNDER:
HTM-1517R :
4:3/16:9 sizes with the width of 270 mm
HTM-1917R :
4:3/16:9 sizes with the width of 360 mm
2) Deflection
a) SDTV
NORMAL SCAN: 4:3/16:9
UNDER SCAN: 4:3/16:9
b)
HDTV
NORMAL SCAN: 16:9
UNDER SCAN: 16:9
HD 4:3 SCAN: Zoom for 4:3 area
3) Deflection distortion
Within ±1% of screen height (Deflection linearity
and raster distortion)
4) Sync stability
Monitor sync keeps stable under the following input
conditions:
Internal sync: ±6dB of rated video input level
External sync:
External sync input level 0.3 to 6Vp-p
5) High voltage
Generated voltage: HTM-1517R : 25kV ± 1kV
HTM-1917R : 26kV ± 1kV
High voltage fluctuation:
Within ±0.5% (150µA reference)
Beam current range within 0 to 600µA
6) Convergence
HTM-1517R :
90% zone of the screen height: Within 0.4mm
90% zone of the screen width: Within 0.5mm
HTM-1917R :
Inside the center circle of
screen height diameter: Within 0.3mm
The rest of the screen area: Within 0.4mm
