3) Input level
a) HDTV (BTA S-001B)
•Y, G, B, R input V: 700mVp-p Positive polarity
S: ±300mVp-p
•Pb, Pr input V: ±350mVp-p Positive polarity
•Sync input: ±300mVp-p
b)
SDTV (SMPTE/EBU N10)
•RGB input VS: 1.0Vp-p Positive polarity
V: 0.7Vp-p Positive polarity
* When all or none of R, G and B have sync
signals, and when only G has sync signal.
•YPbPr input
Y signal WHITE (100%):700mVp-p
SET UP: 0mVp-p
SYNC: 300mVp-p
PbPr signal: 525mVp-p
(100/0/75/0 COLOR BAR)
•Sync input: 0.3-6Vp-p Negative polarity
4) Input impedance
High impedance bridge connection or 75Ω
termination
(75Ω termination plug is optional.)
5) Return loss
More than 46dB (10MHz)
(2) Multi-format SDI input module
(Option)
• DKM-511A (Multi-format SDI module)
Equipped with high performance x/sin x correc-
tion type video signal post-filter
• DKM-511B (Multi-format SDI module)
For preview monitor
• DKM-511AAV/BAV
(Multi-format SDI module supporting embedded
analog audio output)
• DKM511AAVD/BAVD
(Multi-format SDI module supporting embedded
AES/EBU audio output)
Video section
1) Input/output terminal
Input: BNC 2 lines
Output: BNC 1 line (Active loop through for only
one line selected)
2) Input signal format (HD/SD auto detection)
a) HD-SDI
• 1035i/60,59.94
• 1080i/60,59.94
• 1080i/50
• 1080p/24sF, 23.98sF
(When supported by the monitor)
• 720p/60,59.94
• 720p/50
b) SD-SDI(4:2:2)
• 480i/59.94
• 575i/50
3) Input level rating: 800mVp-p±10%
4) Transmission speed
a) HD-SDI: 1.485Gb/s
b) SD-SDI(4:2:2): 270Mb/s
5) Quantization bit rate: 10 bits
6) Input/output impedance:75Ω
7) Return loss: More than 15dB(~742.5MHz)
More than 10dB(742.25~1485MHz)
8) Transmission distance:
Over 100m (5CFB, 1.485Gb/s)
Audio section (AV / AVD type)
Common specifications for embedded audio
1) Compatible embedded audio input formats
SMPTE272M: 480i/59,94(4:2:2)
575i/50(4:2:2)
SMPTE299M: 1035i/60,59,94
1080i/60,59,94
1080i/50
1080p/24sF, 23.98sF
720p/60,59,94
720p/50
2) Format: Auto switching
3) Sampling frequency: 48kHz (Synchronized
with video clock)
Analog audio output (AV type)
* Analog audio level 0dBs 0.775Vrms
1) Output terminal:
XLR-5-32 type
(Canon-made 5-pin male)
2) Line output: Analog audio 2-channel
Active (no-transformer) balanced
output type
3) Rated output level:
+4dBs * Load impedance 10kΩ
(At –20dBFS digital audio level)
4) Max. Output level:
+24dBs * Load impedance 10kΩ
(At 0dBFS digital audio level)
5) Output impedance: 50Ω
6) Min. Load impedance: 600Ω
7) Quantization bit rate: 24 bits/ch
8) Emphasis: 50/15µs digital emphasis
(Auto detection)
9) Frequency response: 20~20KHz±1dB
10) S/N ratio: More than 80dB
11) Dynamic range: More than 80dB
12) Crosstalk: More than 60dB
(1kHz, Max. Output)
13) Harmonic distortion: Less than 0.1%
(Rated output)
