(8) Description of MENU 6 Functions
For operation details, refer to the ASP-80 manual.
①Zerocalibration
②Autowhitebalance(6500K)
③Autowhitebalance(9300K)
④Autowhitebalance(Userdata)
⑤Colortemperature/luminancemeasurementandmemory
⑥Real-timecolortemperature/luminancemeasurement
MENU6<SETUP>(ASP-80)
1.ZEROCARIBRATION
2.AWB(6500K)
3.AWB(9300K)
4.AWB(USERDATA)
5.MEASUREMENT&MEMORY
6.REALTIMEMEASUREMENT


NEXT→(MENU)
SELECT→(ENT)EXIT→(ESC)
① Zero calibration
 Perform the calibration of Auto setup probe.
Connect ASP-80 to the monitor, and make sure to
perform this calibration before proceeding onwards.
 The function is disabled unless Auto setup probe
is connected.
 Be careful not to allow external light into the sen-
sor.
 When the sensor is not receiving light to be mea-
sured, the message “ERROR 1 : TOO LIGHT”
appears.
② Auto white balance (6500K)
 Setup at 6500K
 To execute this setup, an input of 100% window
signal or the window pattern internal test signal
is needed.
③ Auto white balance (9300K)
 Setup at 9300K
 To execute this setup, an input of 100% window
signal or the window pattern internal test signal
is needed.
④ Auto white balance (User data)
 Setup at user color temperature.
 To execute this setup, an input of 100% window
signal or the window pattern internal test signal
is needed.
⑤ Color temperature and luminance measure-
ment and memory
 Measure the color temperature, luminance and ras-
ter luminance of the user setting.
 The results can be stored as USER DATA if neces-
sary.
 Measurable ranges are as follows.
Luminance: 10~190cd/ ㎡
Raster luminance: 0.01~0.99cd/ ㎡
Color temperature (x, y coordinates):
0.250~0.380
⑥ Real-time color temperature and luminance
measurement
 Color temperature and luminance are measured
for real-time display of the readings.
 The function can also be applied to the measure-
ment of other devices.
(9) Description of MENU 7 Functions
* This menu is intended to control the embedded audio module DKM-5**AV/AVD and the embedded audio level
meter module DAM-504/508.
The setting in this menu does not function for a monitor without the above modules.
① Setting the analog audio output
 Select the DKM-5**AV analog audio line output
(2ch) from the four pairs of enbedded audio chan-
nels CH1/2, CH3/4, CH5/6 and CH7/8.
 This function is disabled for the embedded digital
audio output model (DKM-5**AVD).
② Setting the channel of level meter
 Select the display channel of DAM-504/508 from 8-
channel (CH1 TO 8), 6-channel (CH1 TO 6), 4-chan-
nel (CH1 TO 4) and 2-channel (CH1 TO 2) as nec-
essary.
①Settingtheanalogaudiooutput
②Settingthechanneloflevelmeter
③Settingthebrightnessoflevelmeter
MENU7<AUDIO>
1.LINEOUTCH CH1/2
2.LEDENABLE CH1to8
3.LEDDIMMER HIGH


NEXT→(MENU)
SELECT→(ENT)EXIT→(ESC)
 For DAM-504 (4-channel model), the selections of
8-channel and 6-channel are disabled.
③ Setting the bightness of level meter
 Select the brightness of DAM-504/508 level meter
LED from HIGH, MID, LOW and OFF.
 The setting is not applied to the tally (red and
green).
