4-7. MENU Functions
(1) List of MENU
All functions can be executed in the MENU screen.
Table 4-1 List of MENU
MENU MENU1 ①MULTISDIFM SettingtheformatofSDIinputs
 <FORMAT>
 ②RGB/YPBPRFM SettingtheformatofRGB/YPbPrinputs

 ③→1035I/1080I SettingtheformatofRGB/YPbPrinputline

 ④→YPBPR SettingtheformatofRGB/YPbPrinputsignal

 ⑤TESTSIG.FM SettingtheformatofinternalTESTsignals

 ⑥INPUTDISP. SettingthechannelformatdisplayON/OFF


 MENU2 ①CENT.MARKER SettingON/OFFofthecentercrossmarker
 <MODE>
 ②MARKERCOLOR Settingthecolorofmarker

 ③ASPECT Settingtheautomatic/manualaspectratioswitching

 ④CHANGEASPECT Settingtheoperationmodeataspectchange

 ⑤REMOTECONT. Settingthewirelessremotecontroller

 ⑥REMOTENO. SettingtheremoteIDnumber

 ⑦DEGAUSSTIME SettingthedegaussONtimer


 MENU3 ①SELECTFILE SelectingFILE
 <CHANGEDATA>
 ②STOREFILE Selectingthedestinationfile

 ③CHANGEFILE Settingthefilechange

 ④LOADFACTORY Settingtorestoredefault

 MENU4 ①STATUS Displayingstatusinformationofeachdata
 <STATUS>

 MENU5 ①PASSWORDLOCK Settingthedatapasswordlock
 <LOCK>

 MENU6 ①ZEROCALIBRATION Autosetupprobecalibration
<SETUP(ASP-80)>
 ②AWB(6500k) 6500Kautowhitebalance

 ③AWB(9300k) 9300Kautowhitebalance

 ④AWB(USERDATA) Userdataautowhitebalance

 ⑤MEASUREMENT&MEMORY Colortemperature/luminancemeasurementandmemory

 ⑥REALTIMEMEASUREMENT Real-timecolortemperature/luminancemeasurement


 MENU7 ①LINEOUTCH Settingtheembeddedanalogaudiooutput
 <AUDIO>
 ②LEDENABLE Settingthechanneldisplayofaudiolevelmeter

 ③LEDDIMMER SettingthebrightnessofaudiolevelmeterLED


