4
(5) Functions
1) Marker function
a) Center marker: Set to ON/OFF using MENU settings
b) Safe title:
The following markers are displayed according to
the aspect (4:3/16:9).
( ) indicates the aspect when markers are displayed.
① 80%+100% (4:3/16:9)
② 88%+100% (4:3/16:9)
③ 90%+100% (4:3/16:9)
④ 93%+100% (4:3/16:9)
⑤ 5 divided crosshatch (4:3/16:9)
⑥ 10 divided crosshatch (4:3/16:9)
6 patterns with respect to effective viewing
area: 80, 85, 88, 90, 93 and 100%
⑦ Cross (4:3/16:9)
⑧ 14:9 marker (16:9)
⑨ 13:9 marker (16:9)
⑩ 4:3 marker (16:9)
⑪ 4:3 marker + 80% (4:3) marker (16:9)
2) Shadow function
The following shadow is created in the 16:9 mode.
① 4:3marker + 4:3 shadow
② 4:3 marker + 80% (4:3) marker + 4:3 shadow
③ 4:3 shadow
④ 13:9 marker + 13:9 shadow
⑤ 13:9 shadow
⑥ 14:9 marker + 14:9 shadow
⑦ 14:9 shadow
3) Auto setup
The white balance can automatically be adjusted
using the auto setup probe ASP-80 (option).
4) Remote control
a) Parallel remote control channel
COMPOSITE/AUX/HD-SDI/SD-SDI, YPbPr/RGB,
COLOR/MONO, SYNC INT/EXT, 4:3/16:9,
4:3 MARKER ON/OFF, 4:3 SHADOW ON/OFF,
R/G.TALLY ON/OFF
b) Serial remote control
The input interface is equipped as standard and is
capable of controlling most of the monitor functions.
The controller SRC-301Z is optional.
c) Infrared remote control
The infrared remote controller RCT-30A is optional.
5) Internal test signal
The format can be switched by MENU settings.
① Crosshatch
② 50% flat field
③ 100% window
④ Characters
⑤ Staircase waves with pluge signal
6) Beam feedback system (BFS)
7) Menu assist
• Input signal format setting
• YPbPr/RGB switching setting
•Test signal format setting
•Marker center cross display ON/OFF setting
• Marker color setting
• Remote ID setting
• Degauss timer setting
•% display of preset data
• Password setting
• Auto setup setting
• Embedded audio related setting
(6) Memory
1) Memory type
ROM: 64KB programmable ROM
RAM: 32KB static RAM
2) Battery backup
Memory backup time: 10 years or longer
Battery: BR2330-1HF lithium battery
(7) Applicable Standards
1) Safety standards: Conforms to UL60950-1
2) Electromagnetic
interference: Conforms to FCC Class-A
3) X-ray radiation: DHHS
2-2. Individual Specifications
Standard equipped with YPbPr/RGB one-input module
only.
(1) YPbPr/RGB input module
(Standard)
• 1-input module
1) Input/output terminal
a) YPbPr/RGB
YPbPr/RGB: BNC 1 line (Loop through)
Sync signal input: BNC 1 line (Loop through)
2) Input signal format (YPbPr/RGB)
a) SDTV
• 480i/59.94
• 575i/50
• 480p/59.94 (option)
b) HDTV
• 1035i/60,59.94
• 1080i/60,59.94
• 1080i/50
• 1080p/24sF, 23.98sF (option)
• 720p/ 60, 59.94
•720p/50 (option)
