Ikegami HTM-1517R User Manual

13
(3) SD-SDI input module
(4) NTSC/PAL-B decoder input module
CH A
CH B
MONITOR
OUT
SDI
4:2:2
()
SD-SDI A/B input
• Inputthe4:2:2SD-SDIsignalhereaccordingtothefollowingmodule.
• WhenthismoduleandmultiSDImodulearemountedtogether,thismodulewillbeassignedtothe
 2ndslot.Toselectthe2ndslot,pressthe2ndslotswitch.

SD-SDI A output
• TheSD-SDIsignalinputtotheAchanneloutputhere.
SD-SDI B output
• TheSD-SDIsignalinputtotheBchannelis
 outputfromhere.
• Thesignalselectedatthemonitorcanalsobe
 outputfromherebysettingtheconnectorinside
 themodule.

<Setting Method>
NORMAL(Default)
MONITOR OUT
EL 102 EL 101 EL 102 EL 101
DK-801A
Decorder module
NTSC/PAL-B3linecombdecodermodule(DE-811)
NTSC3linecombdecordermodule(DE-801)
CH A
CH A
CH B
CH C
NTSC
PAL
NTSC or PAL-B analog composite input
• InputNTSC/PAL-Banalogcompositesignalhere.
• Ifnotadoptingtheloopthroughconnectionmethod,connecttheterminatedplug.
• Whenusingintheexternalsyncmode,inputtheexternalsyncsignalintotheSYNCinput
 connectorofVIDEOPROCESSmoduledescribedinSection(1)withtheDE-801,andintothe
 SYNCinputconnector(seebelow)ofthesamemodulewiththeDE-811.

EXT SYNC signal input (with the DE-811 decoder module only)
• WhenusingthecompositesignalinputofDE-811intheexternalsyncmode,inputthesyncsignal
 here.TheinputsignalofDE-811isnotcompatiblewiththeSYNCinputofVIDEOPROCESS
 module.TheDE-811module'sSYNCinputisnothandledonothermodules.
• Ifnotadoptingtheloopthroughconnectionmethod,connecttheterminatedplug.
SYNC
NTSC
NTSC
PAL
