Page 4 AMAZON2 SERIES Operation Manual
Pioneer in Digital Vision Technology
1.4. Dimension and Description
Camera Body Size : 29(w) x 29(H) x 51.1(D) mm
Camera Body Weight: approx. 58 gram
1.5. Camera Interface
The AMAZON2 series camera interfaces are located on the back of the camera (assuming the lens mount is up front)
as per the following:
Network condition: Link (LED: Green) Network condition: Act (LED: Red)
8-pin RJ-45 jack
6-pin Receptacle Connector
Ethernet Cable Lock
