1.7. Pixel Data
The AMAZON2 series complies with the AIA GigE Vision version 1.0 where data packets are transmitted by a
Gigabit Ethernet interface.
<YUV (4: 2: 2) format >
U-(K+0) Y-(K+0) V-(K+0) Y-(K+1)
U-(K+2) Y-(K+2) V-(K+2) Y-(K+3)
U-(K+4) Y-(K+4) V-(K+4) Y-(K+5)
U-(K+Pn-6) Y-(K+Pn-6) V-(K+Pn-6) Y-(K+Pn-5)
U-(K+Pn-4) Y-(K+Pn-4) V-(K+Pn-4) Y-(K+Pn-3)
U-(K+Pn-2) Y-(K+Pn-2) V-(K+Pn-2) Y-(K+Pn-1)
<YUV (4: 1: 1) format >
U-(K+0) Y-(K+0) Y-(K+1) V-(K+0)
Y-(K+2) Y-(K+3) U-(K+4) Y-(K+4)
Y-(K+5) V-(K+4) V-(K+4) Y-(K+5)
U-(K+Pn-8) Y-(K+Pn-8) Y-(K+Pn-7) V-(K+Pn-8)
Y-(K+Pn-6) Y-(K+Pn-5) U-(K+Pn-4) Y-(K+Pn-4)
Y-(K+Pn-3) V-(K+Pn-4) Y-(K+Pn-2) Y-(K+Pn-1)
<Mono 8/GR8 Format>
Y-(K+0) Y-(K+1) Y-(K+2) Y-(K+3)
Y-(K+4) Y-(K+5) Y-(K+6) Y-(K+7)
Y-(K+Pn-8) Y-(K+Pn-7) Y-(K+Pn-6) Y-(K+Pn-5)
Y-(K+Pn-4) V-(K+Pn-3) Y-(K+Pn-2) Y-(K+Pn-1)
<Mono 12/ GR12 Format>
High Byte Low Byte
Y-(K+0) Y-(K+1)
Y-(K+2) Y-(K+3)
Y-(K+Pn-4) Y-(K+Pn-3)
V-(K+Pn-2) Y-(K+Pn-1)
