AMAZON2 SERIES Operation Manual Page 49
Pioneer in Digital Vision Technology
Status Control Register
Address Name Field Bit Description
F0F00834h TRIGGER_DELAY Presence_Inq [0] Presence of this feature
0: N/A 1: Available
Abs_Control [1] Absolute value control
0: Control with value in Value field
1: Control with value in Absolute value
CSR if this bit =1, value in Value filed is
ignored
- [2..5] Reserved
ON/OFF [6] Write : ON or OFF this feature
Read : read a status
0: OFF, 1:ON
If this bit=0, other fields will be read only.
- [7..19] Reserved
Value [20..31] Minimum value for this feature control
4.11.1. Strobe Delay / Duration Table
The table shows the strobe index by increment step through the strobe delay time and the strobe duration time.
The increment step is different depending on the strobe index.
Strobe Delay Table
Strobe Index (Y) Increment Step
Strobe Delay Time
Delay Time Range
0 ~ 3900 1 us T=Y us 0 ~ 3900 us
Strobe Duration Table
Strobe Index (Y) Increment Step
Strobe Delay Time
Delay Time Range
1 ~ 200 250 us T=Y*250 us 250 us ~ 50 ms
Index and Time Table for Strobe Delay and Duration
Delay Index (Y) Strobe Delay Time Duration Index (Y) Strobe Duration Time
0 0 us 1 250 us
1 1 us 2 500 us
2 2 us 3 750 us
10 10 us 4 1 ms
100 100 us 10 2.5 ms
1000 1000 us 100 25 ms
3900 3900 us 200 50 ms
