6. User Defined Registers
User defined registers are IMI specific feature registers which IMI cameras are capable of implementing. The user
can utilize extended features of the IMI specific register for an application.
6.1. User Defined Address
Address Description( bit : msb*) Read/Write
0xF2F10000
A/D bit resolution
Bit 28~Bit31 : A/D bit resolution
Please refer to GigE Vision version 1.0 data depth register(address:0xF0F00630)
Read only
0xF2F10004
Auto shutter-speed maximum/minimum value register. (32bit)
In auto shutter mode, the shutter speed value is checked between the auto
shutter-speed maximum value and the minimum value
Read/Write
0xF2F10008
Auto gain maximum/minimum value register.*(32bit)
In auto gain mode, the gain value is checked between the auto gain maximum
value and the minimum value.
Read/Write
