0xF2F10018
Mode control register
Bit 30: SIO enable mode (0: IMI-TECH mode, 1: path through)
Read/Write
0xF2F10110
Trigger noise filter register (External trigger only)
Bit 22~Bit 31: trigger masking range (M, unit: usec, range: 0~999)
Read/Write
0xF2F1011C
Power on default memory channel
Bit 0 ~ Bit 3: power on initial memory channel
Read/Write
0xF2F10200
Camera version register
Bit 16~Bit 31: camera version
(ex: If reading value: 0x00003000, camera version is 3.000)
Read only
0xF2F10120
Bright Level for Iris Control Application
Bit 24 ~ Bit 31: Bright Level for Image Capture
Read only
0xF2F10124
Test Pattern
Bit 0: Vertical Grey Bar
Bit 1: Bias Grey Bar
Read/Write
0xF2F1012C
4 step knee LUT run control register
LUT knee 1st point register
Bit 0: presence inquiry (read only)
Bit 1: LUT regeneration command (self cleared)
Bit 2~Bit4: reserved
Bit 5: enable brightness, sharpness, gamma feature with knee function
Bit 6: On/Off
Bit 7: reserved
Bit 8~Bit 19: X coordination of 1st knee point
Bit 20~Bit31: Y coordination of 1st knee point
Read only
0xF2F10130
LUT knee 2nd point register
Bit 0: presence inquiry (read only)
Bit 1: LUT regeneration command (self cleared)
Bit 2~Bit5: reserved
Bit 6: reserved
Bit 7: reserved
Bit 8~Bit 19: X coordination of 2nd knee point
Bit 20~Bit31: Y coordination of 2nd knee point
Read/Write
0xF2F10134
LUT knee 3rd point register
Bit 0: presence inquiry (read only)
Bit 1: LUT regeneration command (self cleared)
Bit 2~Bit5: reserved
Bit 6: reserved
Bit 7: reserved
Bit 8~Bit 19: X coordination of 3rd knee point
Bit 20~Bit31: Y coordination of 3rd knee point
Read/Write
0xF2F10138
LUT knee 4th point register
Bit 0: presence inquiry (read only)
Bit 1: LUT regeneration command (self cleared)
Bit 2~Bit5: reserved
Bit 6: reserved
Bit 7: reserved
Bit 8~Bit 19: X coordination of 4th knee point
Bit 20~Bit31: Y coordination of 4th knee point
Read/Write
0xF2F1013C
User defined LUT run control register
Bit 0: presence inquiry (read only)
Bit 1~Bit 4: reserved
Bit 5: enable brightness, sharpness, gamma feature with user defined LUT
function
Bit 6: ON/OFF
Read/Write
