AMAZON2 SERIES Operation Manual Page 61
Pioneer in Digital Vision Technology
Bit 7~Bit 11: reserved
Bit 12~Bit 15: run LUT index
Bit 16~Bit 31: reserved
0xF2F10140
LUT save control register
Bit 0: save command
Bit 1: save ready status( read only)
Bit 2~Bit 6: reserved
Bit 7: set LUT write buffer address to 0
Bit 8~Bit 11: save LUT index
Bit 12~Bit 31: reserved
Read/Write
0xF2F10144
LUT data register (block write command)
Save the first data at low word, then second data at high word
Bit 0~Bit 3 : reserved
Bit 4~Bit 15 : the second data
Bit 16~Bit 19 : reserved
Bit 20~Bit 31 : the first data
Write Only
0xF2F10160
User defined AE X-axis value
Bit 0: presence inquiry (read only)
Bit 1~Bit4 : reserved
Bit 5: Make Command
Bit 6: ON/OFF (1: current setting value, 0: current image size)
Bit 7: reserved
Bit 8~Bit 19: DAC or AE X-axis start position at current display image
(AE_SX)
Bit 20~Bit 31: DAC or AE X-axis width at current display image
(AE_WX >= 4)
Read/Write
0xF2F10164
User defined AE Y-axis value
Bit 0: presence inquiry (read only)
Bit 1~Bit 4: reserved
Bit 5: Make Command
Bit 6: On/Off (1: current setting value, 0: current image size)
Bit 7: reserved
Bit 8~Bit 19: DAC or AE Y-axis start position at current display image
(AE_SY)
Bit 20~Bit 31: DAC or AE Y-axis width at current display image
(AE_WY >= 4)
Read/Write
0xF2F10150
Snow noise remove threshold register
Bit 0: presence inquiry (read only)
Bit 1~Bit 5: reserved
Bit6: ON/OFF
Bit8: grid noise filter enable for GR8 mode at color camera (0: disable,1: enable)
Bit 7~Bit23: reserved
Bit 24~Bit31: Threshold Value (T):
If pixel difference value > Threshold Val
ue, the pixel is replaced with near pixel
average value
Read/Write
Threshold Value (T)
0
0 7 8 11
(MSB) (LSB)
Pixel compared threshold value bit map
