AMAZON2 SERIES Operation Manual Page 19
Pioneer in Digital Vision Technology
3.2. Color Cameras
3.2.1. IMC-720G Specification
Features (IMC-720G)
Image Sensor 1/1.8” Interline CCD(ICX274AQ)
Effective Pixels 2,012,208 pixels 1628(H) x 1236(V)
Picture Size 1624x1288
Cell Size 4.4 um x 4.4 um
Real Frame Rate
16 (1624x1288, GR8)
16 (1624x1288, GR12)
16 (1624x1288, YUV411)
16 (1624x1288, YUV422)
30 (800x600, 2x2 binning, GR8)
30 (800x600, 2x2 binning, GR12)
Lens Mount C-mount, CS-Mount
Scanning System Progressive System
Binning 2x2
ROI Partial Scan (Unit: 4x4)
Trigger
Edge Rising Edge or Falling Edge (Photo coupler)
Mode 0, 1, 2, 4, 5, 15
Source External Trigger(Photo-coupler) or Software Trigger
Strobe Support Normal Mode or Trigger Mode(Photo-coupler)
Memory Save/Load 9 Channels(0:factory, 1~4:feature, 5~8:mode/feature)
One-shot/Multi-shot 1 ~ 65535 Shots
Control Functions
Brightness, Sharpness, Gamma, Auto-Exposure, Shutter, Gain, Hue
Saturation, Auto White Balance, User Defined LUT
Digital Interface / Transfer Rate 1000BT, RJ45 / 1Gbps
Gain 0 ~ 18 dB (Manual or Auto control)
Shutter Speed 1 usec ~ 3600 sec (Manual or Auto control)
Data Depth 12 bit
S/N Ratio 56dB or better
Supply Voltage& Power
Less than 3.0W @12 VDC via 6-pin connector
Less than 3.2W @ PoE
External Dimension / Weight 29(W) x 29(H) x 51.1(D) mm / Approx 58g
Operation Temp/ Storage Temp -5°C to 45°C / -30°C to 60°C
Camera Specification AIA GigE Vision version 1.0
Remark: Camera specification described above may be changed without notice
