AMAZON2 SERIES Operation Manual Page 1
Pioneer in Digital Vision Technology
1. Introduction
1.1. Overview
IMI TECH’s Amazon2 Series is compliant with the GigE Vision standard and supports GenIcam Standard. Fairly
new in the image processing industry, GigE is gaining more interest thanks to users who are familiar with the
Ethernet interface and technology. This new interface is expected to lift the barriers of bandwidth limitation found in
other interfaces such as FireWire and USB 2.0. It also resolves the limitation of cable length by supporting 100
meter distance with conventional CAT-5 cable. As GigE is a relatively new standard, we expect more and more
customers to demand new and additional feature support. We also expect a growing desire for software
interoperability due to GigE’s excellent network interface capability. The very small form factor design has expanded
implementation and broadened application areas by eliminating the limits that currently exist due to size and weight.
A large selection of cameras is available and additional cameras are scheduled to be added to the Amazon2 Series
as well. These will consist of various sensor sizes (1/4”, 1/3” 1/2”, 1/1.8”) and resolution (VGA, XGA, SXGA, UXGA)
both in color and black and white. The Amazon2 Series consist of the following models.
AMAZON2
SERIES
Model Name CCD(Progressive) Resolution FPS at Max Resolution
Black &
White
IMB-710G 1/4” 656 x 488 100
IMB-711G 1/3” 656 x 484 91
IMB-712G 1/2” 656 x 484 91
IMB-715G 1/3” 1032 x 776 35
IMB-716G 1/3” 1288 x 964 30
IMB-717G 1/2” 1388 x 1040 20
IMB-720G 1/1.8” 1624 x 1232 16
Color
IMC-710G 1/4” 652 x 484 100
IMC-711G 1/3” 652 x 484 92
IMC -712G 1/2” 652 x 484 91
IMC -715G 1/3” 1032 x 772 35
IMC -715G2 1/3” 1280 x 720 30
IMC -716G 1/3” 1288 x 960 30
IMC -717G 1/2” 1388 x 1036
20
IMC -720G 1/1.8” 1624 x 1228
16
AMAZON2 SERIES’ unique features include a lookup table and external trigger mode 0, 1, 2, 4, 5, 15, one-shot
and multi-shot, a wide range of shutter speeds (1us~3600s), partial scan, and binning modes (2x2 for B&W). All
of these features provide maximum flexibility for a wide variety of applications. AMAZON2 SERIES input signals
are isolated optically to ensure quality images acquisition without the risk of noise degrading the input signal.
Industrial screw lock cable support has been added for more reliable connectivity. AMAZON2 SERIES‘s firmware
