Page 36 AMAZON2 SERIES Operation Manual
Pioneer in Digital Vision Technology
0: OFF, 1: ON
If this bit=0, other fields will be read only.
A_M_Mode [7] Write: set the mode,
Read: read a current mode
0: Manual, 1: Auto
- [8..19]
Reserved
Value [20..31] Value: Write the value in Auto mode, this filed is
ignored.
If “ReadOut” capability is not available, read value
Has no meaning
4.3. Sharpness
The sharpness control feature may be used to compensate low-pass effects caused, for instance, by the special
color interpolation. If you do not prefer such signal manipulation, you may switch it OFF. For sharpness control
inquiry and status register, follow the same definition as “BRIGHTNESS”
4.4. White Balance
Color models have the white balance feature which can be controlled automatically or manually. U/R(Red/Green)
and V/B (Green/Blue) alter the degree to which Red and Blue CCD component pixels are weighed to form composite
pixels. In manual mode you can adjust the white balance by altering the Blue (U/V) and Red Value (V/R). One
Push and Auto White Balance are supportable for Color models.
Inquiry Register
Address Name Field Bit Description
F0F0050Ch WHITE_B
AL_INQ
Presence_Inq [0] Presence of this feature
Abs_Control_Inq [1] Capability of control with absolute value
- [2] Reserved
One_Push_Inq
[3] One push auto mode (Controlled automatically by
camera only once)
ReadOut_Inq [4] Capability of reading the value of this feature
ON/Off_Inq [5] Capability of switching this feature ON and OFF
Auto_Inq [6] Auto mode (Controlled automatically by camera)
Manual_Inq [7] Manual mode (Controlled by user)
Min_Value [8..19] Minimum value for this feature control
Max_Value [20..31] Maximum value for this feature control
Status Control Register
Address Name Field Bit Description
F0F0080Ch WHITE_B
ALANCE
Presence_Inq [0] Presence of this feature. 0: N/A, 1: Available
Abs_Control [1] Absolute value control
0: Control with value in the Value field
1: Control with value in the Absolute value CSR
If this bit = 1, value in the Value field is ignored.
