If Polarity_Inq is “0” Read only ( 0: lowa
active output, 1: High active output)
Delay_Value [8..19]
Delay after start of exposure until the
strobe signal asserts
Duration_Value [20..31]
Duration of the strobe signal
A value 0 means dessert at the end of
exposure function if required.
204h Strobe_1_Cnt Same definition to Strobe_0_Inq
208h Strobe_2_Cnt Same definition to Strobe_1_Inq
20Ch Strobe_3_Cnt Same definition to Strobe_2_Inq
210h
.
.
2FFh
Reserved
4.11. Trigger Delay Control
Based on external triggers, the users can delay image acquisition by the trigger delay control feature. The
Amazon2 Series supports trigger delay control as per the following tables. There is no support in software
trigger mode.
Trigger Delay Table
Mode Value range
Trigger delay Time : T
DelayTime Range
All Cameras 0 ~ 4000
T = Yus 0 usec ~ 4000 usec
Inquiry Register
Address Name Field Bit Description
F0F00534h TRIGGER_DLY_IN
Q
Presence_Inq [0] Presence of this feature
Abs_Control_Inq [1] Capability of control with absolute value
- [2] Reserved
One_Push_Inq [3] One push auto mode (Controlled
automatically by camera only once)
ReadOut_Inq [4] Capability of reading the value of this
feature
ON/OFF_Inq [5] Capability of switching this feature ON and
OFF
Auto_Inq [6] Auto Mode (Controlled automatically by
camera)
Manual_Inq [7] Manual Mode (Controlled by user)
Min_Value [8..19] Minimum value for this feature control
Max_Value [20..31] Maximum value for this feature control
