Page 10 AMAZON2 SERIES Operation Manual
Pioneer in Digital Vision Technology
2. Basic Installation
The Amazon2 series operates in connection with a PC that is running an operation system such as MS Windows.
Basic installation starts by installing the driver, connecting the camera and loading the demo application software.
Please refer to the demo application software manual for details.
2.1. Recommended System Requirement
Requirements Details and Description
Operating System Windows XP, Window 7
CPU Intel Core2quad or better spec
System Memory 2GB or more
Video Adapter 1280 x 1024 with 24 bit color or higher
Hard Disk Drive 40 GB or higher
Optical Drive CDROM or DVDROM
Gigabit Ethernet Interface On
Cable Standard Gigabit Ethernet Cable (RJ45)
Power Supply DC 8V ~ 24V.
Software DirectX 9.0 or higher, IMI Tech Digital Imaging CD
Remark: Other software or hardware may be required for user specific applications.
2.2. Hardware Installation
Basic camera installation is a very simple 3 step process as follows. (Also check the figure below)
Step 1. Locate the Gigabit Ethernet port on the computer.
(Note: Some computers would require the installation of a PCI/ PCI express Gigabit Ethernet interface).
Step 2. Plug one end of the GigE cable into the camera; and the other end of the cable into the computer’s Gigabit
Ethernet port.
Step 3. In not using PoE, plug 12VDC jack of 6-pin receptacle HIROSE Connector to power adaptor.
Basic
Hardware Installation
and
Camera Connection
