45
INSTALLERUSER
MAINTENANCE TECHNICIAN
Programming menu
Menu item Description
Adjustment
range
Default value
Customised
Value
P25 Max fan Speed
is denes the max fan speed and therefore the maximum
relative boiler operating power (RPM speed is calculated by
multiplying the value displayed by 50)
P26 ÷ 255
80 k
W Met. 132
80 kW LPG 131
100 kW Met. 134
100 kW LPG 127
120 kW Met. 140
120 kW LPG 140
P26 Min fan Speed
is denes the min fan speed and therefore the minimum
relative boiler operating power (RPM speed is calculated by
multiplying the value displayed by 50)
0 ÷ P25
80 kW Met. 27
80 kW LPG 25
100 kW Met. 26
100 kW LPG 25
120 kW Met. 26
120 kW LPG 25
P27 Min pump speed
Denes the minimum pump speed in heating mode at the
minimum boiler power. Attention: do not go below 30%
1 ÷ 100 % 30 %
P28
Pump speed during
burner ignition
Denes the minimum pump speed in heating mode during
burner ignition
Attention: do not go below 40 %
1 ÷ 100 % 40 %
P29 DHW conguration
is is used to select the DHW operating mode, choosing
between NTC probe or on/o thermostat
1 = NTC probe
17 = on/o
thermostat
1
P30
Velocità in accensione
ventilatore (Speed
during fan power-on)
is denes the fan speed during burner ignition
Attention: do not change this parameter (RPM speed is
calculated by multiplying the value displayed by 50)
0 ÷ 114 RPM
x 50
(range limited
by parameters
P25 and P26)
44
P31 Unit of measurement
is denes the unit of measure on the display, whether
metric or Imperial
0 ÷ 127 = °C
- kW
128 ÷ 256 = °F -
kBTu/h
0
P32 Set Resc Min
Limits the minimum value of the heating set. (e parameter
takes priority in relation to the value set from the pushbutton
panel)
0
P33
Antifreeze function
activated by the
common ow
probeIt activates the
antifreeze function
launched by the
common ow probe.
e boiler turns on once there is a drop below the set value 2 ÷ 20 °C 5°C
P34
Antifreeze function
deactivated by the
common ow probeIt
deactivates the
antifreeze function
launched by the
common ow probe.
e boiler turns o once the set temperature is reached 2 ÷ 20 °C 15°C
P35
Delayed Activation
/ Deactivation of the
second boiler
With its simple cascade operation, it avoids unnecessarily
turning the second boiler on and o
0 ÷ 255 s econds 60 seconds
P36
Temperature
adjustment
calculation time
is denes the time interval to calculate the boiler
temperature
Attention: do not change this parameter
1 ÷ 10 seconds 3 seconds
P37 0 ÷ 10 V input
It denes whether the boiler must function with the
temperature or probe set0 = temperature set
1 = power set
P38
Common ow probe
conguration
It activates the common ow probe functioning.
0 = no probe
1 = probe
present
