IMO iDrive - Chapter 2 Part Number Description

Chapter 2 Model description
2-1
Chapter 2 Part numbering description
iDrive product rating label (example)
CAUTION
Model: EDX-040-21-E Motor Rating: 0.5HP / 0.4KW
INPUT: AC 1 phase 50 / 60Hz VOLTAGE: 200 – 240V (+10%, -15%) I
RMS
: 5.4A
OUTPUT:AC 3 phases 0 – 200Hz VOLTAGE: 0 - V
IN
I
RMS
: 3.1A
IP20 / UL Open Type (rated -10°C to 50°C Ambient)
IMO Precision Controls Ltd
WARNING: THIS PRODUCT MUST BE EARTHED!
Do not inspect components unless the lamp is off
See manual for correct installation and operation
!
EDX - 040 - 2 1 - E -
Series:
Nominal
motor capacity:
Input
voltage:
Input
phases
EMC filter : Enclosure
020:
0.18kW / 0.25 HP
1:100V 1:Single phase E: Integrated Filter
040:
0.37kW / 0.5 HP
2:230V 3:Three phase Blank: No Filter
N4S: IP65 + water
and dust=proof
switch
075:
0.75kW / 1.0 HP
4:400V
150:
1.5kW / 2.0 HP
N4:IP65 without
water and dust-
proof switch
220:
2.2kW / 3.0 HP
Blank: IP20
