IMO iDrive - Specification; Product Individual Specification

Chapter 3 Environment description and installation
3-13
3.4 Specification
3.4.1 Product individual specification
400V model
EDX-□□□-43(-E)
iDrive
075 150 220
Horse power (HP)
1 2 3
Suitable motor capacity (kW)
0.75 1.50 2.2
Rated output current (AB
RMS
B)
2.3 3.8 5.2
Rated capacity (kVA)
1.7 2.9 4.0
Input voltage range(V)
3PH 380~480V+10%,-15%(50/60Hz)
Output voltage range(V)
3PH 0~480V
Input current (AB
RMS
B)
3.0 4.8 6.6
Net weight (Kg)
1.68
1.70 1.73
Allowable momentary power
loss time (S)
1.0 2.0 2.0
Enclosure
IP20
100V model 200V model
EDX-□□□-11
EDX-
□□□-21(-E) EDX-□□□-23
iDrive
020 040 075 020 040 075 150 220 020 040 075 150 220
Horse power (HP) 0.25 0.5 1 0.25 0.5 1 2 3 0.25 0.5 1 2 3
Suitable motor capacity (kW) 0.2 0.4 0.75 0.2 0.4 0.75 1.5 2.2 0.2 0.4 0.75 1.50 2.2
Rated output current (AB
RMS
B) 1.7 3.1 4.2 1.7 3.1 4.2 7.5 10.5 1.7 3.1 4.2 7.5 10.5
Rated capacity (kVA) 0.53 0.88 1.60 0.53 0.88 1.60 2.90 4.00 0.53 0.88 1.60 2.90 4.00
Input voltage range(V)
1PH
100~120V+10%,
-15%(50/60Hz)
1PH
200~240V+10%,
-15%(50/60Hz)
3PH
200~240V+10%,
-15%(50/60Hz)
Output voltage range(V)
3PH 0~240V
Input current (AB
RMS
B) 7.1 12.2 17.9 4.3 5.4 10.4 15.5 21 3.0 4.0 6.4 9.4 12.2
Net weight (Kg) 0.62 0.68 0.72 0.71 0.73 0.73 1.25 1.3 0.61 0.61 0.66 0.95 1
Allowable momentary power
loss time (S)
1.0 1.0 1.0 1.0 1.0 1.0 2.0 2.0 1.0 1.0 1.0 2.0 2.0
Enclosure IP20
Non-Standard Models Standard Models
