4.2 Parameter functions
Quick-Start ‘A’ parameter function list
Parameter
Number
Function Range / (Units)
Factory
Setting
Notes
A00 Operation control
000: Keypad RUN/STOP keys
001: Terminals
002: RS232/485 Comms
000
A01 Frequency control
000: Keypad UP/DOWN keys
001: Potentiometer on Keypad
002: AIN signal (TM2)
003: MFIT : Mot. Pot. function
004: RS232/485 Comms
000
A02 Frequency high limit 01.0 ~ 200 (Hz) 50.0/60.0 *2
A03 Frequency low limit 00.0 ~ 200 (Hz) 00.0 *2
A04 Acceleration time 1 00.1 ~ 999 (s) 05.0 *1, *2
A05 Deceleration time 1 00.1 ~ 999 (s) 05.0 *1, *2
A06 Control mode select
000: Vector control
001: V/F control
001 *4
A07 V/F Pattern set 001 ~ 007 001
A08 Output voltage at base frequency 198 ~ 264, 380 ~ 528 (V) 220 / 440
A09 Base frequency 00.2 ~ 200 (Hz) 50.0/60.0
A10 Torque Boost Gain [V/F] 00.0 ~ 30.0 (%) 00.0 *1
A11
Electronic thermal overload relay
protection for motor (OL1)
000: Enable motor protection
001: Disable motor protection
000
A12 Access to ‘b##’ parameters
000: b-parameters closed
001: b-parameters open
000
Advanced ‘b’ parameter function list (Access to these parameters by setting A12 = 001)
Parameter
Number
Function Range / (Units)
Factory
Setting
Notes
b00 Acceleration time 2 00.1 ~ 999 (s) 05.0 *1, *2
b01 Deceleration time 2 00.1 ~ 999 (s) 05.0 *1, *2
b02 Slip Compensation Gain [V/F] 00.0 ~ 100 (%) 00.0 *1
b03 Motor No-Load Current [V/F] --- (A) --- *4
b04 Output Voltage at Max Frequency [V/F] 00.0 ~ 100 (%) 100
b05 Mid Output Frequency [V/F] 00.1 ~ 200 (Hz) 25.0
b06 Output Voltage at Mid Frequency [V/F] 00.0 ~ 100 (%) 50.0
b07 Min Output Frequency [V/F] 00.1 ~ 200 (Hz) 00.5
b08 Output Voltage at Min Frequency [V/F] 00.0 ~ 100 (%) 01.0
b09 Motor Rated Current --- (A) --- *4
b10 Motor Rated Voltage --- (V)
---
*4
b11 Motor Rated (Base) Frequency --- (Hz) --- *4
b12 Motor Rated Power --- (KW) --- *4
b13 Motor Rated Speed [Vector] --- (RPM/10) --- *4
