Chapter 4 Software index
4-4
b14 Torque Boost Gain [Vector] 001 ~ 450 (%)
b15 Slip Compensation Gain [Vector] 001 ~ 450 (%)
b16
Low Frequency Dead-Band Voltage
Compensation [Vector]
000 ~ 040
b17 DC Injection Braking Time 00.0 ~ 25.5 (s) 00.5
b18 DC Injection Braking Start Frequency 01.0 ~ 10.0 (Hz) 01.5
b19 DC Injection Braking Level 000 ~ 020 (%) 005
b20 Skip Frequency 1 00.0 ~ 200 (Hz) 00.0 *1
b21 Skip Frequency 2 00.0 ~ 200 (Hz) 00.0 *1
b22 Skip Frequency Bandwidth 00.0 ~ 30.0 (+/-Hz) 00.0 *1
b23 Acceleration Stall Prevention Level 050 ~ 200 (%) 200
b24 Deceleration Stall Prevention Level 050 ~ 200 (%) 200
b25 Running Stall Prevention Level 050 ~ 200 (%) 200
b26 Stall Prevention Deceleration Time 00.1 ~ 999 (s) 03.0
b27 Acceleration Stall Prevention
000: Enabled
001: Disabled
000
b28 Deceleration Stall Prevention
000: Enabled
001: Disabled
000
b29 Running Stall Prevention
000: Enabled
001: Disabled
000
b30 Stall Prevention Time During Running
000: According to (A05)
001: According to (b26)
000
b31 Power Loss Auto Re-start
000: Enabled
001: Disabled
001
b32 Auto Re-start Attempts 000 ~ 005 000
b33 Auto-Start at Power ON
000: Auto-Start Enabled
001: Auto-Start Disabled
001
b34 Reset Mode
000: Reset command available
if RUN command is OFF
001: Reset command available
if RUN is ON or OFF
000
b35 Terminal S1 Function 000
b36 Terminal S2 Function 001
b37 Terminal S3 Function 005
b38 Terminal S4 Function 006
b39 Terminal S5 Function
000: RUN Forward
001: RUN Reverse
002: Preset Speed Command 1
003: Preset Speed Command 2
004: Preset Speed Command 3
005: JOG Frequency Command
006: Emergency STOP (E.S.)
007: Base Block (b.b.)
008: Select Accel 2 / Decel 2
009: Reset
010: UP Command
011: DOWN Command
012: Control Signal Switch
013: Communications Mode
014: Accel. / Decel. Prohibit
015: Master / Auxiliary Speed
Signal
007
