Chapter 4 Software index
4-5
b40 Terminal S6 Function 009
b41 Terminal AIN Function
016: PID Disabled
017: Analog Frequency Signal
Input Terminal AIN
018: PID feedback signal (AIN)
017
b42 Frequency UP/DOWN Control (MFIT)
000: UP/DOWN Control ON
(Freq. Held at Power OFF)
001: UP/DOWN Control ON
(Freq. Reset to 0Hz at OFF)
002: UP/DOWN Control ON
(As 000 – UP/DOWN is
Available when Output OFF)
000
b43 S1 ~ S6 Digital Input Scan Time 001 ~ 100 (mS x 8) 010
b44 Jog Frequency 00.0 ~ 200 (Hz) 05.0 *1
b45 Preset Frequency 1 00.0 ~ 200 (Hz) 05.0 *1
b46 Preset Frequency 2 00.0 ~ 200 (Hz) 05.0 *1
b47 Preset Frequency 3 00.0 ~ 200 (Hz) 10.0 *1
b48 Preset Frequency 4 00.0 ~ 200 (Hz) 20.0 *1
b49 Preset Frequency 5 00.0 ~ 200 (Hz) 30.0 *1
b50 Preset Frequency 6 00.0 ~ 200 (Hz) 40.0 *1
b51 Preset Frequency 7 00.0 ~ 200 (Hz) 50.0 *1
b52 Preset Frequency 8 00.0 ~ 200 (Hz) 60.0 *1
b53 0-10V Analogue Output Select
000: Output Frequency
001: Set Frequency
002: Output Voltage
003: DC Voltage
004: Output Current
005: PID feedback Signal
000 *1
b54 Analogue Output Gain 00.0 ~ 200 (%) 100 *1
b55 Multi-Function Output Relay RY1
000: RUN
001: Frequency Reached
(± b57)
002: Frequency in Range
(b56 ± b57)
003: Frequency Detected
(>b56)
004: Frequency Detected
(<b56)
005: Fault
006: Auto Reset / Restart
007: Momentary Power Loss
008: Emergency Stop (E.S.)
009: Base Block (b.b.)
010: Motor Overload
011: Inverter Overload
012: xxx Not Used xxx
013: Power ON
014: Communication Error
015: Output Current (>b58)
000
b56 Output Frequency Reached Set Value 00.0 ~ 200 (Hz) 00.0 *1
b57 Frequency Detection Range 00.0 ~ 30.0 (±Hz) 00.0 *1
