b58 Output Current Reached Set Value 000 ~ 100 (%) 000
b59 Output Current Detection Time 00.0 ~ 25.5 (S) 00.0
b60
Multi-Function Output Transistor
(T+ / T- Option Card)
000: RUN
001: Frequency Reached
(± b57)
002: Frequency in Range
(b56 ± b57)
003: Frequency Detected
(>b56)
004: Frequency Detected
(<b56)
005: Fault
006: Auto Reset / Restart
007: Momentary Power Loss
008: Emergency Stop (E.S.)
009: Base Block (b.b.)
010: Motor Overload
011: Inverter Overload
012: xxx Not Used xxx
013: Power ON
014: Communication Error
015: Output Current (>b58)
005
b61 AIN Signal Select
000: 0-10V
001: 4-20mA
000
b62 AIN Gain 000 ~ 200 (%) 100 *1
b63 AIN Bias 000 ~ 100 (%) 000 *1
b64 AIN Bias
000: Positive
001: Negative
000 *1
b65 AIN Slope Direction
000: Positive
001: Negative
000 *1
b66 AIN Analogue Input Scan Time 000 ~ 100 (mS x 4) 050
b67 PID Operation Mode
000: PID Control Disabled
001: PID Bias D Control
002: PID Feedback D Control
003: PID Bias D Reverse
Control
004: PID Feedback D Reverse
Control
000
b68 Feedback Gain 0.00 ~ 10 (%) 1.00 *1
b69 P: Proportional Gain 0.00 ~ 10 (%) 01.0 *1
b70 I: Integral Time 00.0 ~ 10 (s) 10.0 *1
b71 D: Differential Time 0.00 ~ 10 (s) 0.00 *1
b72 PID Bias/Offset
000: Positive Direction
001: Negative Direction
000 *1
b73 PID Bias Adjust 000 ~ 109 (%) 000 *1
b74 PID Filter Time 00.0 ~ 02.5 (s) 00.0 *1
b75 PID Sleep Level 00.0 ~ 200 (Hz) 00.0
b76 PID Sleep On-Delay Time 00.0 ~ 25.5 (s) 00.0
b77 Serial Communications Address 001 ~ 254 001 *3 *4
