Chapter 4 Software index
4-7
b78 Serial Communications Baud Rate
000: 4800 (bps)
001: 9600
002: 19200
003: 38400
003 *3 *4
b79 Stop Bits
000: 1 Bit
001: 2 Bits
000 *3 *4
b80 Parity Bit
000: No Parity
001: Even Parity
002: Odd Parity
000 *3 *4
b81 Data Bits
000: 8 Bits
001: 7 Bits
000 *3 *4
b82 Communication Error Detection Time 00.0 ~ 25.5 (s) 00.0 *3
b83 Communication Error Response
000: Decelerate to Stop (A05)
001: Coast to Stop
002: Decelerate to Stop (b01)
003: Continue to Run
000 *3
b84 Remote Keypad Frequency Control From
000: UP/DOWN Keys
001: Potentiometer (VR)
000
b85 Remote Keypad Broken Cable Response
000: No Response
001: Motor Stop as set by b92
002: No Stop, Runs at Set Freq
000
b86 Carrier Frequency 004 ~ 016 (kHz) 010
b87 Inverter Cooling Fan
000: Auto Run by Inverter °C
001: Run When Output On
002: Always Run
003: Always Stop
001
IP20
Only.
b88 Motor Rotation Direction
000: Forward
001: Reverse
000 *1
b89 Inverter Power Code (Read Only) See following description
b90 RUN / STOP / Direction Switching
000: FWD/STOP-REV/STOP
001: RUN/STOP-FWD/REV
002: 3-Wire – RUN/STOP
000
b91 Reverse RUN Instruction
000: Reverse Enabled
001: Reverse Disabled
000
b92 STOP Method
000: Decelerate to STOP
001: Coast to STOP
000
b93 Operation Monitor
000: Display Hz Only
001: Display Hz, A, V, PID, etc
000
b94 Copy Module
000: Module Disabled
001: Copy iDrive to Module
002: Copy Module to iDrive
003: Read / Write Check
000 *3
b95 All Data Reset to Factory Settings
010: Reset to Default (50Hz)
020: Reset to Default (60Hz)
000
b96 Software Version (Read Only) CPU Version *3 *4
b97 Alarm Log Last 3 fault records *3 *4
