Note: If the carrier frequency is increased the output current from the inverter will be de-rated
according to the following table.
Output current (A) derating with increasing carrier frequency
b87 Cooling fan control
000: Auto-run by inverter temperature
001: Run when inverter output is ON
002: Always running.
003: Always stopped.
1.) b87 = 000: The fan is thermostatically controlled in order to extend the life of the fan.
2.) b87 = 001: The fan runs when the inverter output is running.
3.) b87 = 002: The fan runs when power supply is ON.
3.) b87 = 003: The fan does not run at any time (Care needed as inverter damage could occur)
b88 Motor rotating direction 000: Forward
001: Reverse
Only when A00 = 000, inverter operation is controlled by keypad.
b89 Inverter capacity code (Input voltage – Output kW/HP)
b89 iDrive Rated Output Power b89 iDrive Rated Output Power
1P2 110V - 0.18 / 0.25
203
220V – 2.2 / 3.0
1P5
110V - 0.37 / 0.5
401
400V – 0.75 / 1.0
101
110V - 0.37 / 1.0
402
400V – 1.5 / 2.0
2P2
220V - 0.18 / 0.25
403
EDX
400V – 2.2 / 3.0
2P5 220V - 0.37 / 0.5
201
EDX
220V - 0.75 / 1.0
202 220V – 1.5 / 2.0
EDX-
020-11,
Carrier
frequency
020-21,
020-23
040-11,
040-21,
040-23
075-11,
075-21,
075-23
150-21,
150-23
220-21,
220-23
075-43 150-43 220-43
4~10KHz 1.7 3.1 4.2 7.5 10.5 2.3 3.8 5.2
12KHz
1.7 3.1 4.2 7.5 10.5
14KHz
1.6 3.0 4.0 7.0 10
16KHz 1.5 2.8 3.8 6.8 9.8
