User Manual PROFview XL 5 Technical Specifications
5 Technical Specifications
General parameters and overview of functions
Field of application PROFIBUS DP and FMS to IEC 61158 (formerly EN 50170 or DIN 19245)
Bit sampling • 8-fold (quality level and errors)
• 16-fold (disturbance-free voltage range and edges)
Signal sampling (oscilloscope display) 192 MSample/s, 2,400 sampling points
Triggering to a station • to frames (SD1...SD4) with a certain source address
• to a short acknowledgment (0xE5, target address of the request frame)
Supported baud rates • 9.6; 19.2; 45.45; 93.75; 187.5; 500 kbit/s and 1.5; 3; 6; 12 Mbit/s
• Automatic detection via baud rate scan
Station list (live list) • Master /slave differentiation
• Automatic detection via station scan
• Specification of ID number and distance
• Automatic sorting by topological order
Topology determination • Active with integrated master simulator
• All masters disconnected from the bus
• Accuracy: ±2 m; maximum distance: 230 m
Management of measuring points • Option of measuring at different measuring points
• Automatic sorting by the station list
Quality level and errors (one/all stations) • Value of the signal quality (typ. 200 ... 5,000)
• Glitch, edge and level error counters
• Minimum value and maximum value storage
• Time stamp
• Long-time measurement (logger)
Disturbance-free voltage range and edges • Disturbance-free voltage range (typ. 0.4 ... 5 V, resolution 50 mV)
• Edge steepness (falling and rising, specified in 1/16th of the bit width)
• Minimum value and maximum value storage
• Time stamp
Oscilloscope display • Section of the signal waveform of a station
• Two cursors for measuring the reflection (with taking into account the signal
propagation delay)
• Zoom (six stages)
Frame display • Complete frame recording
• Decoding to PROFIBUS DP (hexadecimal, decimal, ASCII representation)
Statistics of measuring points Statistical evaluation of individual stations for all measuring points: quality level, dis-
turbance-free voltage range and edges
Automatic evaluation Limit value settings and measured-value evaluation according to:
• critical quality level
• critical disturbance-free voltage range
• critical edge
Bus status • Permanent display of the bus status
• Measuring of the differential voltage in the idle state of the bus
Bus cycle time (token rotation time) • Permanent display of the token rotation time for the/a master (0.1 ... 1,000 ms)
• Minimum and maximum value storage
• Address of the master detected
Illegal frames Permanent display of detected frame errors (protocol errors, 0 ... >50,000)
Test record Comprehensive, configurable measuring and test record on DIN A4:
• Letterhead with tester and customer contact data
• Tabular representation of the measured values
• Graphical representation of the measured values
Export function • Measuring data as a configurable CSV file
• Graphical measured-data representation as a bitmap (.bmp)
Firmware and FPGA configuration can be updated via USB
Standards
Equipment safety EN 60950-1: 2003-03
EMC
• Low-frequency interference emission:
• High-frequency interference emission:
• Interference immunity:
EN 61000-3-2: 1995, +A1: 1998, +A2: 1998, +A14: 2000
EN 55022: 1998
EN 55024: 1998
Table 3: Technical specifications
PROFview XL 31
