5 Technical Specifications User Manual PROFview XL
Electrical parameters
Supply voltage 11 ... 36 V DC
Current input 0.6 ... 0.15 A
Measuring of the differential voltage between
A and B
typ. 0.4 V ... 5 V
Potential difference between the connections
PROFIBUS, USB and oscilloscope
< 50 V DC (or < 71 V AC)
Trigger output for the oscilloscope BNC socket, electrically isolated, H pulse, 10 bits wide, level approx. 5 V
Mechanical parameters
Supply voltage connection Extra-low voltage socket to DIN 45323
PROFIBUS connection 2 x 9-pin SUB-D socket
PC connection Self-powered device to USB Specification 1.1; additionally, electrically isolated
Trigger output for the oscilloscope BNC socket, electrically isolated
Housing Aluminum extruded profile
Temperature range • Operation: 5 °C ... 40 °C
• Storage: -20 °C ... 60 °C
Humidity • Operation: 20 % ... 80 % (non-condensing)
• Storage: 20 % ... 80 % (non-condensing)
Degree of protection of the housing IP20 to EN 60529
Dimensions 35 mm x 109 mm x 143 mm
Weight approx. 320 g
Table 4: Technical specifications (cont'd)
Warning:
The PBT is a Class A device. Such devices can cause interference in residential areas. In this case, the plant
operator can be requested to take appropriate measures and to bear the costs for such measures.
32 PROFview XL
