IDS 430/433 Users Manual Version 1.0
- 11 -
Installation and Setup
This section provides information about unpacking, installing, and setup of the
IDS 433/430. It also directs the installer to the appropriate sections of the
manual for hardware and setup installation.
Unpacking the IDS 433/430
Installation begins with unpacking the IDS 433/430. Observe any instructions or
cautions, which appear in the shipping container. Check the items in the shipping
container against the following item check list or the packing list. IDS, Inc. will not
accept responsibility for shortages against the packing list unless notified within
30 days. All equipment and accessories are inspected and tested by IDS before
shipment. Inspect the equipment carefully. If shipping damage is evident, notify
the carrier immediately. Take photographs if necessary. You are responsible for
final claim and negotiations with the carrier. Save the packing and shipping
container in case you need to store, return, or transport the IDS 433/430 for any
reason.
Item check list
• IDS 433/430 - Weight Scale Indicator
• Power cord
• This user's manual, Scale Basic manual and quick reference guide
• Capacity labels
• A sheet that describes the capacity label placement
NOTE: The container may include additional items that have been purchased
separately.
Installation Guide
Connect IDS 433/430 to load cell
Connect the load cell to the Load Cell Terminal Block located inside IDS
433/430’s enclosure. See the HARDWARE INSTALLATION AND WIRING
section for pin assignments and a sample cable drawing.
Connect IDS 433/430 to the printer (optional)
The IDS 433/430 can be connected to a printer using Com Port 1 (TB3) for
RS232, Current Loop or RS485 interfaces or by using the TTL I/O Port (TB4) for
TTL compatible interfaces. See Hardware and Wiring Diagrams for pin
assignments and sample cable drawings. See Set Operation Parameters, and
Parameter Functions for other communication setup parameters.
