Industrial Data Systems IDS 430 - Scale Parameters

IDS440 Users Manual version 4.2 Set Operation Parameters
22
Scale Parameters
No Parameter Name Default Max Value Pas Field Setting
1 Loadcell mv/v 3 4 3
2 Digital filter 9 18 3
3 Display Update Rate 1 200 3
4 Motion delay time 6 250 3
5 Motion band 6 250 3
6 Motion blanks display 0 (no) 1 3
7 Zero tracking delay 0 250 3
8 Zero tracking band 12 250 3
9 Push button zero percent 100 100 3
10 Primary units type 1 (lb) 6(oz) 3
11 Decimal point position 0 4 3
12 Count-by 1 100 3
13 Alternate units type 2 (kg) 6(oz) 3
14 Alt decimal point 1 4 3
15 Alternate count-by 5 100 3
16 Alt conversion factor 45,360 3
17 Full Scale display digits 10,000 120,000 3
18 Over Weight dd 10,200 120,200 3
19 Deadload offset 3
20 Disable Power-On Zero 1 1 3
21 Deadload Factor 3
22 Weight conversion fact. 3
I/O Port Parameters
No Parameter Name Default Max Value Pas Field Setting
23 Serial port 1 mode 4(8N1) 6 2
24 Serial port 1 baud rate 1(9600) 6 2
25 Serial port 2 mode 4(8N1) 6 2
26 Serial port 2 baud rate 1(9600) 6 2
27 TX2 control / Station Id 255 255 1
28 TX2 Data Format 1 (AND) 4 2
29 Printer port select 2 (Com1) 2 2
30 Autoprint LF after CR 1 (yes) 1 2
31 End Of Print character 12 (ff) 255 2
32 Print label 32 16 char 2
33 Print label 33 16 char 2
34 Print label 34 16 char 2
84 Print label 84 30 char 2
85 Print label 85 30 char 2
86 Print label 86 30 char 2
87 Print label 87 30 char 2
