IDS440 Users Manual version 4.2 Built In Application Programs
14
# 2 Checkweigh: Under/Between/Over
The indicator monitors the scale for activity. When the scale goes above the ‘empty’
weight, the indicator waits for stable weight, and then outputs an indication of Under,
Between (OK), or over. The cycle resets when the scale goes below the empty weight.
Installation
Connect TTL outputs to relay or lamp actuators.
Under weight indication TTL 1 TB4 - Pin 1
Between weight indication TTL 2 TB4 - Pin 2
Over weight indication TTL 3 TB4 - Pin 3
Ground GND TB4 - Pin 16
Configure ‘empty’ scale weight. (Parameter 43)
Operators Functions
Enter setpoint weights
Press the F1 key. The display prompts “SP 1. Use the numeric keyboard to enter
setpoint 1, then press the ENTER key. The display prompts “SP 2”. Use the numeric
keyboard to enter setpoint 2, then press the ENTER key. NOTE: use the F2 key to enter
a decimal point if needed.
Recalculate
Press the F2 key to re-check the weight on the scale.
