IDS440 Users Manual version 4.2 Parameter Functions
45
4. Use the UNITS key (↓) or the PRINT key (↑) to scroll through the parameter
numbers. Press the CLEAR key to exit from the current Event number. Press the
CLEAR key again to exit from event monitor data entry.
Function 72 Scale Basic Function Editor
Use function 72 to create or modify Scale Basic functions. See the “Scale Basic / Event
Monitor” manual for more information on Scale Basic functions.
1. Hold the CLEAR key down and press the ENTER key to enter the configure mode.
2. Enter CFG 72. The IDS440 prompts “Fn”. Enter the function number to be
modified.
3. The IDS440 prompts “0- xxx” where 0- is entry zero, and xxx is the current value for
entry zero. Enter new data for 0- or press the ENTER key to use the displayed data.
4. Use the UNITS key (↓) or the PRINT key (↑) to scroll through the entry numbers.
Press the CLEAR key to exit from the Function Editor.
Function 73 Initialize Function Memory
The initialize function erases function memory and setpoint monitor memory, and
initializes all parameters with password level 1 or 2.
Function 73 prompts “rs Fn” . Press the Enter key to initialize only or enter a number
below to activate a built in program.
1. Fill to Setpoint.
2. Checkweigh: Over/Between/Under
3. Weigh-in / Weigh-out
4. Axle Weigh – Short Scale
5. Axle Weigh – Long Scale
6. ID Tare and Total
7. Peak Hold
Function 74 Configure Timers
The display prompts “tr” when function 74 is activated. Enter the timer number to be
modified (1 to 5) then press the ENTER key. The first parameter (L) is the time length in
tenths of a second. The second parameter (Fn) is the function number to be executed
when the timer times out.
Parameter 75 Enable Peak Detect
Enter a 1 to enable peak detect, enter a 0 to disable peak detect.
