Print Format Design Example
EXAMPLE PRINT:
EXAMPLE FORMAT DESIGN WORKSHEET:
Page:1 Item Description Line No. Column Item No.
E1 Gross Weight 3 4 5
E2 Tare Weight 4 4 6
E3 Net Weight 5 4 7
E4 Time and Date 7 1 10
E5 End of Print 0 0 0
NOTE: A zero in the Line No column terminates printing. Use zero only after all
required information has been entered. The maximum number of entries is 16. If
the 16
th
entry is used, a line number 0 is not required.
Default Print Formats
The print formats (PAGES) are initialized to the following factory settings when
the IDS 430/433 is initialized.
Page 1 Item Description Line No. Column Item No.
E1
The Displayed Weight 1 1 18
E2
End of Print 0 0 0
Page 2 Item Description Line No. Column Item No.
E1 Gross Wt. (primary units) 3 5 5
E2 Tare Weight (primary units) 4 5 6
E3 Net Weight (primary units) 5 5 7
E4 End of Print 0 0 0
1111111111222222222233333333334
COLUMN
1234567890123456789012345678901234567890
LINE
1
2
3 GROSS 54785 LB
4 TARE 12451 LB
5 NET 42243 LB
6
7 TIME 03:45 PM DATE 05 AUG 1999
