InfiNet Wireless R5000 Technical User Manual
Copyright © 2004-2010 by InfiNet Wireless
13
IDU with E1/T1 ports
IDU with E1/T1 ports can be supplied with 2-4 E1/T1 ports. Below there is an
IDU with 2 ports.
Front panel
Rear panel
Indicators modes tables for IDU with E1/T1 ports.
Fuse failure indicator (Check Fuse)
Indicator (red) Status
Off Fuse is okay
On Fuse failure
Power indicator (Power On)
