InFocus X2 Service Manual

X2 Service Manual 42
Before beginning
Make sure the work surface where you perform the functional tests is level and clean. Place the projector
on a soft surface (such as an anti-static mat) when running the tests.
Connect the following to the I/O panel on the projector:
DVD player through component video, composite video and S-video ports
Computer through VESA cable
Perform the following tests
Test Verification
Power Up
Connect AC power, and turn
the unit on.
Verify that the proper splash (logo) screen appears.
Verify image quality.
Cosmetics and mechanicals
Adjust the projector so that the
image is square. Make sure
the lens is at a 90° angle to
the wall.
Verify that the elevator and leveling foot are functional.
Verify that the focus and zoom rings operate properly.
Verify cosmetics.
Component video from DVD
player
1. Press the Source
button on the keypad
to select a video
source.
2. Connect the
component video
adapter cable and to
the projector.
3. Disconnect any other
video sources.
Verify that the video automatically synchronizes.
Verify there is no distortion, noise or other abnormalities.
Composite video from DVD
player
1. Connect the
composite video cable
to the projector.
2. Disconnect any other
video sources.
Verify that the video automatically synchronizes.
Verify there is no distortion, noise or other abnormalities
S-Video from DVD player
1. Disconnect any other
video sources.
2. Connect the S-video
cable to the projector.
Verify that the video automatically synchronizes.
Verify there is no distortion, noise or other video abnormalities.

InFocus X2 Specifications

General

Number of colors	16.78 million colors
Native aspect ratio	-
Projection distance	- m
Vertical scan range	50 - 85 Hz
Projection technology	DLP
Contrast ratio (typical)	2000:1
Screen size compatibility	- \
Projector native resolution	SVGA (800x600)
Focal length range	- mm
Number of built-in speakers	1
Lamp type	SHP
Lamp power	200 W
Service life of light source	3000 h
Full HD	No
Analog signal format system	NTSC, PAL
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	- dB
Placement	Desktop
Product type	Standard throw projector
Product color	Gray
Power consumption (standby)	- W
Harmonized System (HS) code	85286200

Weight and Dimensions

Weight	3100 g
