InFocus X2 Service Manual

X2 Service Manual 66
FRUs by alphabetic listing
Part Name Part Number Parts List Name
Bottom case 505-1839-xx BOTTOM CASE, X2
Controller ECA 510-1907-xx ECA, CONTROLLER BD
(MMA PCB ASSY)
Elevator kit 505-1848-xx ELEVATOR KIT, X2
Fan, 60 mm 526-0193-xx FAN, 60MM EZL12NM002
Fan, 80 mm 526-0192-xx FAN, 80MM EZL12NH003
Fastener kit 505-1860-xx FASTENER KIT, X2
Focus Ring (user replaceable part) 340-1117-xx FOCUS RING
Front Bezel 505-1838-xx FRONT PANEL
ECA kit (includes speaker, keypad
ECA, IR ECA and AC filter ECA
510-1908-xx ECA, PWR INPUT
BD/KEYBD/IR BD
ASSEMBLIES
Label kit 020-2135-xx LABEL KIT, X2
Lamp Door (user replaceable part) 505-1841-xx LAMP DOOR
Lamp housing 505-1859-xx LAMP HOUSING &
THERMO/LEAF SW ASSY
Lamp Module (user replaceable part) SP-LAMP-018
Lens Cap (user replaceable part) 505-1247-xx LENS CAP
Leveling Foot 340-1118-xx FOOT, ADJUSTABLE
Optical Engine 505-0021-xx X2 ENGINE ASSY
Power Supply Kit (includes power
supply and AC filter ECA)
520-0124-xx S/A, PS ASSY – TSUNAMI
PLUS
Rear Bezel 505-1837-xx REAR COVER, X2
Top Case 505-1840-xx TOP COVER
Zoom Ring (user replaceable part) 340-1116-xx ZOOM RING

InFocus X2 Specifications

General

Number of colors	16.78 million colors
Native aspect ratio	-
Projection distance	- m
Vertical scan range	50 - 85 Hz
Projection technology	DLP
Contrast ratio (typical)	2000:1
Screen size compatibility	- \
Projector native resolution	SVGA (800x600)
Focal length range	- mm
Number of built-in speakers	1
Lamp type	SHP
Lamp power	200 W
Service life of light source	3000 h
Full HD	No
Analog signal format system	NTSC, PAL
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	- dB
Placement	Desktop
Product type	Standard throw projector
Product color	Gray
Power consumption (standby)	- W
Harmonized System (HS) code	85286200

Weight and Dimensions

Weight	3100 g
